Hengwang construction machinery products mainly include excavator, road roller, crawler dumper, forklift, cranes, self-loading concrete mixer trucks and backhoe loaders, etc., which are widely used in various construction sites.
Parameter name | DH13-C2 XL (Extended version) | DH13-C2 LGP (Super-wetland version) |
Performance parameters | ||
Operating weight (Kg) | 13400kg/29542lb (With traction frame) | 14000kg/30864lb (With traction frame) |
Ground pressure (kPa) | 45.3 | 34.9/37.9 |
Engine | ||
Engine model | QSB6.7 | QSB6.7 |
Rated power/rated speed (kW/rpm) | 116/2000 | 116/2000 |
Overall dimensions | ||
Overall dimensions of machine (mm) | 4924*3060*2988 | 4924*3380*2988 |
Driving performance | ||
Forward speed (km/h) | 0~10km/h (6.2mph) | 0~10km/h (6.2mph) |
Reversing speed (km/h) | 0~10km/h (6.2mph) | 0~10km/h (6.2mph) |
Chassis System | ||
Center distance of track (mm) | 1780 | 2000 |
Width of track shoes (mm) | 560 | 760/700 (Swamp type track shoe) |
Ground length (mm) | 2640 | 2640 |
Working Adaptability:
● The machine incorporates a dual-circuit electronically controlled hydrostatic drive system to ensure exceptional load adaptability, both when carrying a load and maneuvering on-site. It offers seamless speed regulation, enabling precise control and achieving optimal flexibility, efficiency, and remarkable construction performance, particularly in narrow areas.
● The chassis system boasts an elongated ground length, substantial ground clearance, stable driving, and remarkable maneuverability. Depending on the specific working conditions, it can be equipped with an environmental sanitation blade, ripper, and winch to enhance operational capabilities. Additionally, the standard LED working lamps provide enhanced illumination intensity, ensuring improved visibility and thereby promoting higher levels of safety and reliability during nighttime operations.
